    New Design Voice Coil Micro Motor Movement High Frequency Motor

    Ask Lasest Price
    Brand Name : SUPT
    Model Number : VCAR0008-0064-00A
    Certification : ce, ISO9001
    Supply Ability : 80 Piece/Pieces per Week
    Price : $90.00/pieces >=2 pieces
    Payment Terms : T/T
    Delivery Time : General 5-7 days delivery, fast 3-5 days, bulk to be negotiated
    • Product Details
    • Company Profile

    New Design Voice Coil Micro Motor Movement High Frequency Motor

    Cheap New Design Voice Coil Motor High Frequency Of Movement Small Size

    Product Description

    The VCAR series of Cylindrical Actuators constitute nearly 80% of the market ,they can productce a high force with a high acceleration rates.Peak Forces range for 0.7N to 3000N.Typically ,their stroke length is less than 50mm The VCAR Series Actuators Applications include valve Actuators,Z Axis pick and place,small accurate positive displacement metering pumps and both vibrators and active vibration dampening systems. Markets include Medical semiconductor,Aerospace and Automotive.


    Technical Parameters:

    Product Model Peak Force
    (N)
    Continuous Force
    at 25℃(N)
    Total Stroke
    (mm)
    Max Voltage
    (V)
    Back EMF Constant
    (V/m/s)
    Weight of the coil
    (g)
    Stator Diameter (mm) The Length
    (mm)
    VCAR0001-0064-00A 0.88 0.28 6.4 6.9 0.29 3 9.5 17.7
    VCAR0001-0010-00A 0.73 0.42 1 4.8 0.6 2.7 24 11.2
    VCAR00025-0127-00A 2.55 0.81 12.7 11.6 0.77 .6.6 12.7 24
    VCAR0006-0039-00A 6.2 1.9 3.9 6.6 1.12 7.9 20 17.2
    VCAR0006-0050-00A 6.2 2.6 5 15.7 3.57 8.2 25 18.2
    VCAR0007-0040-00A 7.2 2.4 4 7.5 1.88 7 14.2 23
    VCAR0007-0064-00A 7.8 2.5 6.4 9.9 1.5 7.2 19.1 23.8
    VCAR0007-0127-00A 7.1 2.3 12.7 12.8 1.6 11.4 19.1 27
    VCAR0011-0050-00A 11.4 2.1 5 11.8 3 11.2 24 17.2
    VCAR0011-0100-00A 10.5 2.9 10 43.8 3.5 20 31 26.8
    VCAR0013-0030-00A 13 3.5 3 16 3.5 12 25 21
    VCAR0013-0072-00A 13 4.2 7.2 26.6 5.72 16.2 26.2 24.7
    VCAR0014-0250-00A 14 4.5 25 26.5 3.9 35 25.4 44.2
    VCAR0015-0062-00A 15 6.5 6.2 26.2 9.75 14.8 33 25.6
    VCAR0022-0098-00A 22 6.6 9.8 24.7 5.8 20 34.1 35
    VCAR0022-0448-00A 22 11.4 44.8 14.3 4 52 48 75.7
    VCAR0025-0630-00A 25.3 8 63 50.6 5 68 31.8 83.1
    VCAR0030-0150-00A 29.4 4.73 15 40.5 7.4 27 30 31
    VCAR0032-0050-00A 32 8.9 5 29.3 7.1 48 40 41.7
    VCAR0033-0099-00A 33 8 9.9 24.3 5.87 23.5 36 26.7
    VCAR0033-0224-00A 33 13.5 22.4 26.7 6.8 69 58 72
    VCAR0035-0090-00A 35 11 9 26.4 9 33 25.4 44.3
    VCAR0035-0105-00A 35 15.6 10.5 11.9 5 91 50 67
    VCAR0044-0040-00A 44 16.3 4 18.3 8.9 46.5 53 21.2
    VCAR0044-0059-00A 44.1 17.7 5.9 14.3 8 43 46 22
    VCAR0044-0075-00A 44 13.7 7.5 16.8 7.6 38.6 31.1 35.9
    VCAR0044-0249-00A 44 11.7 24.9 44.9 8.88 65.9 38.1 51.3
    VCAR0070-0149-00A 70 27.3 14.9 26.9 17.7 79 43 53.7
    VCAR0075-0200-00A 75 30 20 26.2 15.2 65 70 38.7
    VCAR0080-0129-00A 80 35 12.9 27.7 18 149 49 53.8
    VCAR0087-0062-00A 87 21.67 6.2 34.5 12.7 45.2 43.1 34.9
    VCAR0087-0563-00A 87 17.5 56.3 63.4 8.1 177 72 110
    VCAR0105-0164-00A 105 35.4 16.1 20.1 11.5 150 60.4 40.4
    VCAR0110-0380-00A 110 37.4 38 23.2 9 150 60.4 60.4
    VCAR0113-0089-00A 113 35 8.9 31 17.5 125 73 27.5
    VCAR0115-0065-00A 115 30.1 6.5 35 17.3 52 40 58
    VCAR0130-0310-00A 130 40 31 30.4 20.5 280 75.6 56.5
    VCAR0140-0150-00A 140 42.2 15 33.4 26.6 80 53 53.7
    VCAR0210-0254-00A 210 66.2 25.4 56.6 28 230 43.7 111.8
    VCAR0262-0112-00A 262 111 11.2 35.1 41 285 71 64
    VCAR0262-0249-00A 262 112 24.9 28.2 26 785 66 109.1
    VCAR0294-0498-00A 294 56.8 49.8 114 24.5 685 93 136.9
    VCAR0436-0187-00A 436 147.6 18.7 40.7 40.7 648 80.4 91
    VCAR0436-0250-00A 436 167 25 31.6 37.2 775 78.4 110
    VCAR0436-0373-00A 436 142.6 37.3 38 29.8 1050 76 163
    VCAR0980-0249-00A 980 605 24.9 41.5 104 1426 126 134.5
    VCAR1351-0310-00A 1351 376.8 31 73.5 68 1071 110 143.7

    Applications:

    Small voice coil motors are commonly used in semiconductors for precision positioning and drive applications. It can be embedded into tiny devices such as semiconductor lasers, optical modules, and micromechanical systems (MEMS). Through precise current control, voice coil motors can achieve micron-level precise positioning and fast response, and can provide continuous driving force under the limitation of miniature size. This makes small voice coil motors widely used in the fields of semiconductor manufacturing and micro-nano technology, for tasks such as controlling optical components, adjusting the focal length of lenses, performing fine mechanical adjustments, and realizing high-precision automatic control.

    New Design Voice Coil Micro Motor Movement High Frequency Motor

    Our Services

    Technical indicators & specifications can be customized

    Satisfactory after-sales service

    New Design Voice Coil Micro Motor Movement High Frequency Motor

    Company Information

    New Design Voice Coil Micro Motor Movement High Frequency Motor

    Certifications

    New Design Voice Coil Micro Motor Movement High Frequency Motor

    FAQ

    1.Voice coil motor uses AC or DC power?
    The voice coil motor is fully named permanent magnet synchronous DC motor, so it uses DC power.

    2.Is the permanent magnet motor a brushless motor or a brush motor?

    Permanent magnet motor is a brushless motor.
    A permanent magnet motor uses a permanent magnet to replace the current coil to generate a magnetic field, and is an integrated product consisting of the motor body and driver. The brushes are an important component of a direct current motor, while the rotor of a brushless motor is made of permanent magnetic material and the stator is a coil winding. The rotor of a brushed motor is made of wire windings, and the stator is a permanent magnetic material.
